Planar Silicon Super Fast Rectifier MURF1020CT/MURF1030CT/MURF1040CT/MURF1060CT ITO220AB

Model NO. : MURF1040CT

Luminous Intensity : None Luminance

Color : None Luminance

Structure : Planar

Material : Silicon

Transport Package : Tube

Specification : High Power Package

Trademark : JF, JH

Origin : China

HS Code : 85411000

Supply Ability : 10000000000piece/Year

Package Size : 20.00cm * 40.00cm * 15.00cm

Package Gross Weight : 8.000kg

Place of Origin : China

Certification : ISO9001:2015, ISO14001:2015, IATF16949

MOQ : 3,000 Pieces

Price : Negotiable

Delivery Time : Peak Season Lead Time: one month Off Season Lead Time: within 15 workdays

Payment Terms : LC, T/T, PayPal

Contact Now

SUPER FAST RECTIFIER DIODES
Electronics Component

Part Number: MURF1020CT/MURF1030CT/MURF1040CT/MURF1060CT

Major Parameter:

Type	VRRM	IF	IR(25ºC)	IR(100ºC)	IR(125ºC)	VF	Trr	Outline
Type	V	A	μA	uA	uA	V	nS	Outline
MURF1020CT	200	2×5	5.0		50	0.975	35	ITO-220AB
MURF1030CT	300	2×5	5.0		50	1.3	35
MURF1040CT	400	2×5	5.0		50	1.3	35
MURF1060CT	600	2×5	5.0		50	1.7	35

Brand: JF / JH

Package: ITO-220AB package
Manufacturer: Jinan Jingheng Electronics Co., Ltd.

Features:

Plastic package has Underwriters Laboratory Flammability Classification 94V-0

Single rectifier construction

High surge capability

For use in low voltage ,high frequency inverters, free wheeling ,and polarity protection applications

High temperature soldering guaranteed:2 0 C/10 seconds, 0.25"(6.35mm)from case

Fast switching for high efficiency

Low forward voltage drop

Component in accordance to RoHS 2011 65 EU

Application:
Used in power supply, lighting, auto, home appliance field

Planar Silicon Super Fast Rectifier MURF1020CT/MURF1030CT/MURF1040CT/MURF1060CT ITO220AB

Planar Silicon Super Fast Rectifier MURF1020CT/MURF1030CT/MURF1040CT/MURF1060CT ITO220AB Images
